Configuring user mapping groups using the configuration menu

Log in to the NDR as npadmin using the NDR IP address or FQDN. For example:

$ ssh npadmin@10.1.0.1

or

$ ssh npadmin@exampleFQDN

Enter privileged mode:

npadmin@ia> enable

Enter the npadmin password. The password can be 5 to 24 characters long.

[sudo] password for npadmin: <password>

Enter configuration mode:

npadmin@ia# configure system

Enter configuration CAC mode.

npadmin@ia(config)# authorization

In the CAC/PIV configuration menu, select 2 to configure Active Directory. The Active Directory configuration menu appears.

Select 7 to add the user attributes for the X.509 certificates to the uiapi group mapping field for authorization (for example, [CN=engpxuiapi,OU=AdminGroups,OU=Engineering,DC=testad,DC=eng,DC=fireeye,DC=co m]). Press Enter.

Select Q to save your changes and exit the menu
