The NS9500 Sensor requires a license to activate the baseline throughput of 10 Gbps. Additional license is required to increase the throughput from 10 Gbps to 20 Gbps or 30 Gbps. The license is provided as a .zip or .jar file. The Manager supports both formats. The license procured contains the details for the throughput for the Sensors.
Note
You must first purchase a license to enable traffic inspection in the NS9500 Sensor. To obtain a license, contact the Sales team.
You can upload the license from the Licenses page in the Manager. In the Manager, select Manager → <Admin Domain Name> → Setup → Licenses.
The following details are displayed in the Capacity tab:
.jpg "GUID-51255DDD-9247-410F-B413-511FF6F2FEBF-low.jpg")
Option | Definition |
|---|---|
Required | Model – Sensor model compatible with the license Capacity – Throughput limit for the license Device Count – Number of devices that can be assigned to the license |
Assigned To | Name of the Sensor assigned to the license. |
License Details | Customer – Customer for whom the license file was generated Grant ID – The Trellix Grant ID of the corresponding customer Key – The license key number. Expiration – Applicable only for demo and subscription licenses
Type – Displays if the license is Perpetual, Subscription, or Evaluation (Demo) type.
|
Added | Time – Date in <mmm-yy> format, and time when the license was added By – Name of the user who added the license |
Comments | Enables you to add your comment per license file that is imported. Double-click in the Comment field and enter your comment. Click outside this field and your comment is automatically saved. |
.png)
.png)
.png)
The following actions can be performed in the Capacity tab:
