View summary details of a selected Cluster

Published on Sep 11, 2026

1 minute(s) read

Details about the Cluster is available in the Manager.

Task

In the Manager, go to Devices → <Admin Domain Name> → Devices → <Cluster> → Summary.

The device Summary page is displayed.

Summary details of a virtual security system

Option definitions
Option	Definition
Status	Displays whether there are pending changes to be deployed to the virtual security system or if it is up to date. Green indicates that the system is up to date and blue indicates that there are pending changes to be deployed.
Device Type	The type of device, for example, Cluster
Trellix Virtual IPS Controller	Displays the name of the Controller
vIPS Protected Group	Displays the name of the vIPS Protected Group
Member Instances
Name	Displays the status and name of the instance
Protections	Displays the Software, Signature set, and Callback Detector versions of the Sensor
Last Deployment	The time stamp of previously deployed pending changes
Sensor	Version - Displays the version of the Sensor Virtual Probe - Displays the version of vIPS Probe
Instance ID	Displays the ID of the Controller
Last Reboot	Displays the time stamp of last reboot performed

To view details of a managed endpoint, click View VMs.
To restart the Sensor, click Member Sensor Actions → Reboot.
To run a diagnostic trace for the Sensor, click Member Sensor Actions → Run diagnostics.
To export the Sensor software information in the form of a .csv file, click Save as CSV.
